Brand New Ugoos AM6 TV Box Amlogic S922 pre-release

Posted in Apr 3, 2019 in TV Boxes, no comment

Ugoos revealed a brand new device coming soon: Ugoos AM6 TV Box based on Amlogic S922X device.

Ugoos AM6

New TV Box combines all the best hardware and software solutions from previous models and abilities of Amlogic next gen processor – 12nm S922X.

AM6 will get USB 3.0 Fast USB, Bluetooth 5.0, WIFI 5.0/2.4 GHz with MIMO RSDB Technology Support, Wake on LAN function, active fan with control and other improvements.

The device will come with Android 9 OS on board.

Hardware specification
CPU: Amlogic S922X 12nm,Quad core ARM Cortex-A73 and dual core ARM Cortex-A53 CPU
GPU: ARM MaliTM-G52 MP6
Operating system: Android 9.0
RAM: 2GB  LPDDR4 (3GB/4Gb optional)
Storage capacity(flash memory ): 16GB EMMC(8GB/32Gb optional)
WIFI: AP6398S 2.4G+5G MIMO RSDB.
The wireless module complies with IEEE 802.11 a/b/g/n/ac 2×2 MIMO standard and it can achieve up to a speed of 867Mbps with dual stream in 802.11n to connect the wireless LAN.
Bluetooth: BlueBooth  5.0
Network: 1000M EthernetIntegrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII
interface
SPDIF YES
CEC support
RTC support
HDR support
AV decode: Audio:MP3,WAV,WMA,MPEG,PCM,AC3 etc.
Video/Picture VP9 Profile-2 up to 4Kx2K@60fps
H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps
AVS2-P2 Profile up to 4Kx2K@60fps
H.264 AVC HP@L5.1 up to 4Kx2K@30fps
H.264 MVC up to 1080P@60fps
MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)
WMV/VC-1 SP/MP/AP up to 1080P@60fps
AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps
MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
RealVideo 8/9/10 up to 1080P@60fps
Multiple language and multiple format sub-title video support
MJPEG and JPEG unlimited pixel resolution decoding
(ISO/IEC-10918)
Supports JPEG thumbnail, scaling, rotation and transition
effects
Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso,
*.mp4, *.rm and *.jpg file formats
Video/Picture Encoding
Independent JPEG and H.265/H.264 encoder with
configurable performance/bit-rate
JPEG image encoding
H.265/H.264 video encoding up to 1080P@60fps with low
latency
Video Output Built-in HDMI 2.1 transmitter including both controller and PHY with
CEC, Dynamic HDR and HDCP 2.2, 4Kx2K@60 max resolution
output
o CVBS 480i/576i standard definition output
o Supports all standard SD/HD/FHD video output formats: 480i/p,
576i/p, 720p, 1080i/p and 4Kx2K
External storage: USB HOST 3.0*1
USB HOST 2.0*3
HDMI: HDMI 2.1 Type-A 4Kx2K@60fps max resolution
AV output: AUX+CVBS 480i/576i
Port: TF Card x1
POWER INPUT: DC 12V/2A

Ugoos AM6
