Ugoos UT5 TV Box Pre-release
Official information about next Brand TV Box based with brand new RK3399 chipset.
Ugoos UT5 Specs
Operation System: Android 6.0
Languages: English / Multi-Language support
Chipset: RK3399 28nm Dual Core Cortex-A72 + Quad Core Cortex-A53
GPU: Mali860 MP4 OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11
Supports AFBC
SDRAM: DDRIII-2133 4G
Nand Flash: 32GB Nand Flash (optional: 16/32/64GB)
Storage Extension: Support SATA, 2.5 Inch or 3.5 Inch, Max 8TB
MicroSD (TF) card, Max to 256GB
Network: AP6359S, 2.4GHz*2/5GHz*2 Wi-Fi 802.11 a/b/g/n and 802.11 AC.
Support: LAN 10M/100M/1000M Base-T
Bluetooth: upport BT 4.2 Module
Power Supply: DC 12V/3A
Interfaces
HDMI – 1 x HDMI (A type Female), HDMI2.0, Support 4Kx2K decode output 60fps
USB Ports – USB3.0 x 1， Type-A x 1， USB2.0 x 2
Type-C Support appointed VR sets
Fiber-optical Output: 1 x SPDIF
Card Reader: 1 x TF
SATA: 1 x SATA
Network port: 1 x RJ45
Power Supply: 1 x DC Jack
Antenna: Wi-Fi external 5 dB antenna *3
Media Parameters
Video Decoder H.265 4096*2304 60fps
H.264 4096*2304 60fps
VP9 4096*2304 60fps
MPG4 1920*1080 60fps
Full video format decoding support:
Formats MPEG-1, MPEG-2, MPEG-4, H.263, H.264, AVS, VC-1, RV, VP6/VP8, Sorenson Spark, MVC
Video Encoder H.264, MOV, 3GP
RV, VP6/VP8, Sorenson Spark, MVC
Video Output
HDMI output: Support 4Kx2K (4096×2304) @60HZ HDR
H.265 Data Rate
Up to 60fps.
Software Extension: Support Play market & APK install.
Protocols: Support DLNA, Miracast Protocol, Support DRM requirement, airplay, Audio push.
Certificates: CE, RoHs.
New RockChip3399 gives incredible abilities for mobile platforms and mini PC devices. Rockchip has unveiled the RK3399 processor back at CES 2016 and this SoC now becomes a heart for new Chromebooks performed by ASUS. As you can see from the specs this is our first Branded TV Box with SATA port and HDD holder. Device will able to connect 2.5 and 3.5 inch hard drives. As you can see, we built small OLED screen in order to display status messages and some additional information. USB type-C port we placed on front panel for more convenience.
Ugoos UT5 will be presented on CES 2017 in Las Vegas next January. Everybody will be able to test device and left quote for pre-order.
