Unboxing Beelink GS-King X Dual HDD NAS Hi-Fi Audio System Smart 4K TV Box

Posted in Jul 2, 2020 in Unboxing, no comment

Best Deal Alert! You can now buy Beelink GS-King X Dual HDD NAS Hi-Fi Audio System Smart 4K TV Box from BanggoodGeekbuying or Gearbest.

Beelink GS-King X

Meet Beelink GS-King X Smart 4K TV Box
This amazing Android TV Box surprises us with its large metal box, inside which we have the powerful Amlogic S922X-H SoC and accommodation for two 3.5″ SATA disks with support up to 32TB. Beelink GS-King X runs Android 9.0 out of the box, with Google Assistant and Widevine L1 DRM. The Beelink GS-King X includes the Amlogic S922X-H SoC, a Hexa Core manufactured in 12nm with 4x ARM Cortex-A73 processors capable of reaching 1.8Ghz + 2 RAM Cortex-A53 processors that reach 1.9Ghz. The GPU is an ARM Mali-G52 MP6. At the VPU level we have the Amlogic Video Engine (AVE-10) processor with all kinds of HDR support, Dolby Vision, Advanced HDR10, HDR10+ and HLG among others. The RAM is 4GB LPDDR4 and the storage is 64GB eMMc expandable thanks to an SD card reader. It has WiFi aC 2T2R + Bluetooth with internal antennas.
At the interface level we have the on the back another two USB 3.0 ports, Gigabit Ethernet network connector, three audio connectors SPDIF + Audio (L / R) 3.5mm + RCA Output + Bal Audio (L / R) 6.25mm, connector HDMI 2.1 with 4K@75fps support HDR compatible and Dolby and DTS 7.1 sound. This TV box features high-end Hi-Fi lossless sound quality and Dolby sound effects to give you an immersive hearing and viewing experience, which is one of the most cost-effective products.

The remote control is equipped with a microphone for working with a TV set-top box using voice commands. With the help of an IR transmitter, the media player is only turned on and off, and the rest of the commands from the console and the voice is transmitted via a 2.4G transmitter. Rubber buttons are easily pressed, and the case is comfortable on the palm of your hand.

Beelink GS-King X Smart 4K TV Box Features
– Make Your Home A Cinema. Beelink GS-King X adopts the latest Amlogic S922X-H chip (Quad-core Cortex-A73 @ 2.2 GHz + Dual-core Cortex-A53 @ 1.8 GHz), which is the strongest chip in TV box at present. This TV box features high-end Hi-Fi lossless sound quality and Dolby sound effects to give you an immersive hearing and viewing experience, which is one of the most cost-effective products.
– DTS Listen + Dolby Audio. Beelink GS-King X features DTS listen + Dolby audio decoding, offering Hi-Fi losses sound quality to you for an immersive experience.
– Amlogic S922X-H Hexa-core CPU + Hexa-core ARM G52 MP6 GPU. With the high-performance CPU + GPU, making the GT-King Pro TV box runs fast and smoothly with excellent heat-dissipation, never worry about buffering and overheat while you are watching movies or playing games.
– 4GB RAM + 64GB ROM. 4GB RAM + 64GB ROM storage memory allows you to display HD video smoothly and download massive resources from the Internet, it is enough to store large numbers of movies and Applications and browse the web etc.
– 2.4GHz + 5.8GHz Wifi. Dual-band dual WiFi connectivity for efficient, stable data and video output on your device 24/7. 2.4G plus 5.8G dual-WiFi and 1000Mbps LAN run internet, streaming, and audio perfectly without jerking, which allows you to play 4K @ 60fps, 3D, and H.256 videos smoothly.
– Android 9.0 OS. Running on Android 9.0 operation system for strong compatibility, it is compatible with more software, games, and applications to improve user experience.
– 2.4G Voice Remote Control. Just speak to the 2.4G voice remote control, and it will operate the TV box based on your demand, such as the best action movies, today’s weather, or the latest news.
– Support 4K 75fps Resolution. Support multi-video decoder up to 4K x 2K @ 75fps + 1 x 1080P @ 75fps, which provides much more detailed and better-looking image.
– Unique Skull Design. With the design of the skull pattern style, it is also an exquisite ornament when you place the equipment for your bedroom, sitting room.
– Support multi-video decoder up to 4K x 2K @ 75fps + 1 x 1080P @ 75fps, which provides much more detailed and better-looking image.

How To Start The Second System
● Insert the included SD card into the card slot. Power on will start the second system.
● After inserting 8 GB  CoreELEC micro SD card, the boot option is the second system in the SD card.

Beelink GS-King X Smart 4K TV Box Ports
1 x Power On/Off button
3 x USB 3.0 Port
1 x USB 2.0 OTG Port
1 x micro SD card / TF card slot
1 x Headphone jack 3.5mm
1 x DC in port
1 x HDMI 2.1 connector
1 x RJ45 LAN port (1000 Mbps)
1 x RCA output port (L/R)
1 x Balance output port (L/R)
1 x AV (CVBS) jack 3.5mm
1 x SPDIF port
1 x Infrared Receiver
1 x Power LED light
2 x SATA 3.0 port (internal)
1 x Reset Button

Beelink GS-King X Smart 4K TV Box Specifications
Brand: Beelink
Model: GS-King X
Type: Dual HDD NAS Hi-Fi Audio System Smart 4K TV Box
System: Android 9.0
CPU: Amlogic S922X-H
GPU: Arm Mali G52 MP6
RAM: 4GB DDR4
ROM: 64GB eMMC
Max. Extended Capacity: 128GB
Extended 2 x 3.5 Inches SATA HDD Drive Bay for up to 32TB Storage
Extended Storage TF Card: up to 128GB
5G WiFi: Yes
WIFI: 802.11 a/b/g/n/ac
Bluetooth: Bluetooth 4.1
Power Supply: Charge Adapter
Language: Multilanguage
HDMI Version: 2.1 Output Up to 4K@75Hz
HDMI Function: HDCP
Power Consumption: 8W
RJ45 Port Speed: Gigabit 1000Mbps
Power Type: External Power Adapter Mode
Power Adapter Input: 100-240V / 50-60Hz
Color: Black
Product weight: 1.07 kg
Product size (L x W x H): 16.50 x 11.80 x 10.60 cm / 6.5 x 4.65 x 4.17 inches
System version: 64Bit
Android Security patch level: August 5, 2018
Kernel version: 4.9.113
Build number: 912P0_wol

Package content

1 x Beelink GS-King X Smart 4K TV Box
1 x Power Adapter 5V 2A model TDX-1903000E
1 x HDMI Cable
1 x Voice Remote Control with receiver
4 x HDD Bracket
1 x Multi-language User Manual (English / German / Spanish / Italian / French / Russian / Japanese)
1 x HDD installation Manual (English / Chinese)
1 x Dual OS card
1 x 8 GB  CoreELEC micro SD card
10 x Screw

Photo gallery full album here. Official website here. More about Beelink devices here.
