Unboxing Ugoos AM7 Amlogic S905x4 Android 11 TV Box

Posted in Sep 20, 2021 in Unboxing, no comment

Best Deal Alert! You can buy Ugoos AM7 Amlogic S905x4 Android 11 TV Box from Ugoos.com / Aliexpress.com / Banggood.com for a very good price.

Meet UGOOS AM7 Smart TV Box
Ugoos AM7 gets 4GB Memory and 32GB internal storage, works on Android 11 OS. Device can support AV1 and other well-know Video Formats. Internet connection works due to fast 1Gbit LAN and WIFI 6 MIMO brand new wireless chipset and two Dual-band antennas on board. For different accessories connections, AM7 uses Bluetooth 5.0 LE. USB Type C OTG Port on board with USB 3.0. Different ports versions make double abilities to connect and use a wider row of peripheral devices.

The design of the Ugoos AM7 is very simple but with some elegant touches, it is just a square black plastic box with a slight bend on the sides which is very compact and at 300g is light compared to its components.
Although it is made of plastic, it has a good build quality and looks sturdy, has a Ugoos logo on top with LED lighting showing the status of the TV box, and unusually, it doesn’t have an LED screen on the front.

From the bottom are ventilation holes and four rubber legs for more stability, and there are also some holes on the side of the front that gives an aesthetic appearance and more facilitate the movement of air and cool the device.

Moving on to the ports, there is a wide range of ports that are better than what we often find on TV Boxes, includes 1 x USB 2.0 port, 3 x USB 3.0 ports, 1 x TypeC (OTG), AV-OUT & 3.5mm, SPDIF digital audio out, RJ-45 Gigabit Ethernet port, HDMI 2.1, DC 12V, 2 antenna ports & the power button..

Despite strong hardware, this is really a TV box that almost fits in your hand. You can easily hide it even in a limited space under the TV. This inexpensive TV box contains everything that an enthusiast of movies and TV series can expect, turning your television into a true home entertainment center. Regardless of whether you’re planning to watch videos, play games or listen to music, this TV Box will serve you well. Another instant hit from Ugoos!

UGOOS AM7 Smart TV Box
– WiFi 6 & 2×2 MIMO. WiFi with MIMO standard provides simultaneous and relatively faster connection for better live performances and faster data transfer.
– Bluetooth. Ugoos AM7 supports Bluetooth 5.0 technology. Bluetooth 5 LE is up to 2 times faster then other TV Boxes with Bluetooth v4.2.
– Android 11 as OS. Ugoos AM7 runs the latest stable Android 11.
– Gamepad Settings. Brand Ugoos feature for gamers. Reach greater results in games now, when you can customize your game controller at your own taste.
– OTA (Over-the-air) Updates. When your device get an update, you will be the first who knows about this. Just stay connected and the system will install it automatically.
– Samba server. Turns every Brand Ugoos TV Box in a simple file server. Simple installing and basic security let you share files in your localș network very easy.
– Wake Up on LAN. Wake Up your Ugoos AM7 connected by LAN using your PC or Mobile device in your local network.

UGOOS AM7 Smart TV Box Highlights
– Android 11 operation system
– Amlogic S905x4 CPU, Quad core, 4 x ARM Cortex A55
– ARM Mali-G31 MP2 as GPU
– 2T2R 802.11 a/b/g/n/ac/ax WiFi6 MIMO
– 1000M Ethernet Integrated IEEE 802.3 10/100/1000MB Ethernet MAC with RGMII
– Support Bluetooth 5.0
– Support 4K ultra HD image display
– Support AV1 & H.265 decoding
– USB 3.0 & Type-C OTG ports.

UGOOS AM7 Smart TV Box Specs
Brand: Ugoos
Model: AM7
Type: Android TV Box
CPU: Amlogic S905X4 Quad core ARM Cortex-A55
Operating system: Android 11
Storage capacity (flash memory): 32GB EMMC
WIFI chip: AP6275S 802.11a/b/g/n/ac/ax WiFi6 2T2R MIMO
Bluetooth: v5.0 with LE technology / Broadcom BCM43752 chipset
Network: 1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII
HDMI: HDMI 2.1 Type-A 4Kx2K@60fps max resolution
AV output: AUX+CVBS 480i/576i
Key output: Power
Power Input: DC 5V/3A
Support: HDR / CEC / RTC
Remote Controller Battery: 2 x AAA Battery (not included)
Software Extension: Support Google Play & APK install
DLNA, Miracast Protocol: Support DLNA, Miracast Protocol
IM Software: Support Skype/QQ/MSN/GTALK (Depends on APK )
Office Software: WORD/EXCEL/PDF (Depends on APK install)
Operation Temperature: 0~60℃
Storage Temperature: -10~60℃
Humidity Environment: 5%-90%(No condensation)
Certificate: CE, FCC
Product weight: 300g
Product size (L x W x H): 11.3×11.3×2.6 cm / 5.12 x 4.72 x 0.79 inches
Color: White
Firmware version: updated at first boot from version 1.0.0 to version 1.0.2

UGOOS AM7 Smart TV Box Interface
3 x Full size USB 3.0
1 x Full size USB 2.0
1 x USB Type-C OTG
1 x Charging DC 5V port
1 x HDMI 2.1 out
1 x AV jack output
1 x Ethernet LAN RJ45 port 1Gbit
1 x Optical audio out
1 x Update button
1 x Reset button
1 x Power on / off button
2 x WiFi antenna
1 x Led Work Light

Package content
1 x Ugoos AM7 Amlogic S905x4 Android 11 TV Box
2 x Dual-band Antenna
1 x HDMI Cable
1 x Power Adapter model R122-0503000ED 5V 3A
1 x English User Manual
1 x IR Remote control

Photo gallery full album here. Official webpage here. More about Ugoos devices here.
