Unboxing UGOOS AM6 S922X Android 9.0 TV Box

Posted in Jul 30, 2019 in Unboxing, no comment

Best Deal Alert! You can buy UGOOS AM6 S922X Android 9.0 TV Box from Gearbest.com for a very good price with free shipping.

UGOOS AM6

Meet UGOOS AM6 Smart TV Box
This new Ugoos TV Box combines all the best hardware and software solutions from previous models and abilities of Amlogic next gen processor – 12nm S922X. AM6 has USB 3.0 Fast USB, Bluetooth 5.0, WIFI 5.0/2.4 GHz with MIMO RSDB Technology Support, Wake on LAN function, active fan with control and other improvements.

Packing box looks about the same and continues design line of Ugoos AM3, so housing does. Basically, it is the same but a little bit bigger housing with extra ports and effective ventilation. Rubber legs provide air flow under the lower lid and perforation on the front panel provides access for IR signal and additional air.

The device looks classic and continues the line of Ugoos Brand Products. Most noticeable distinctive feature is two WiFi MIMO antennas placed on the left side of TV Box. Other sides ports configuration is pretty standard: 1 x USB 3.0, 1 x USB 2.0, SD card slot, AV port and AUX IN on the right side, another 2 x USB 2.0, LAN port, HDMI 2.0, SPDIF port and DC jack on the tail side.
Despite strong hardware, this is really a TV box that almost fits in your hand. You can easily hide it even in a limited space under the TV. This inexpensive TV box contains everything that an enthusiast of movies and TV series can expect, turning your television into a true home entertainment center. Regardless of whether you’re planning to watch videos, play games or listen to music, this TV Box will serve you well. Another instant hit from Ugoos!

UGOOS AM6 Smart TV Box Highlights
– High-End spare parts. Samsung groundbreaking LPDDR4 transfer data faster with less energy.
– WiFi. Powerful Ampack AP6398S 2.4G+5G wireless module complies with IEEE 802.11 a/b/g/n/ac and 2×2 MIMO. WiFi with MIMO standard can reach speed up to 867 Mbps with dual stream in 802.11n to connect the wireless LAN. MIMO function provides simultaneous and relatively faster connection for better live performances and faster data transfer.
– Bluetooth. Ugoos AM6 supports Bluetooth 5.0 technology. Bluetooth 5 LE is up to 2 times faster then other TV Boxes with Bluetooth v4.2.
– Android 9.0 Pie as OS. Ugoos AM6 runs the latest stable Android Pie.
– Gamepad Settings. Brand Ugoos feature for gamers. Reach greater results in games now, when you can customize your game controller at your own taste.
– OTA (Over-the-air) Updates. When your device get an update, you will be the first who knows about this. Just stay connected and the system will install it automatically.
– Samba server. Turns every Brand Ugoos TV Box in a simple file server. Simple installing and basic security let you share files in your localș network very easy.
– Wake Up on LAN. Wake Up your Ugoos AM6 connected by LAN using your PC or Mobile device in your local network.

UGOOS AM6 Smart TV Box Features
● Android 9.0 operation system
● Amlogic S922X CPU, Quad core, ARM Cortex-A73, 1.7GHz + Dual core ARM Cortex A53 1.8GHz
● ARM Mali-G52 MP6 (6ppc) GPU
● 2GB LPDDR4 RAM + 16GB EMMC ROM
● 2.4GHz + 5GHz dual band WiFi, IEEE 802.11 a/b/g/n/ac and 2×2 MIMO
● 1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII
● Support Bluetooth 5.0
● Support 4K ultra HD image display
● Support H.265 decoding

UGOOS AM6 Smart TV Box Specs
Brand: Ugoos
Model: AM6
Type: Android TV Box
CPU: Amlogic S922X with 12nn  2.0G HZ,Quad core ARM Cortex-A73 and dual core ARM Cortex-A53 CPU
GPU: ARM MaliTM-G52 MP6 (6ppc)
Operating system: Android 9.0
RAM: 2GB  LPDDR4 (4GB optional)
Storage capacity (flash memory): 16GB EMMC (8GB/64GB optional)
WIFI: AP6398S 2.4G+5G SISO Receiver. The wireless module complies with IEEE 802.11 a/b/g/n/ac 2×2 MIMO standard and it can achieve up to a speed of 867Mbps with dual stream in 802.11n to connect the wireless LAN
Bluetooth: v5.0 with LE technology
Network: 1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII
HDMI: HDMI 2.1 Type-A 4Kx2K@60fps max resolution
AV output: AUX+CVBS 480i/576i
Key output: Power
Power Input: DC 12V/2A
WIFI Module: AmPack 6398S
HDR: Support
Remote Controller Battery: 2 x AAA Battery (not included)
Software Extension: Support Google Play & APK install
DLNA, Miracast Protocol: Support DLNA, Miracast Protocol
IM Software: Support Skype/QQ/MSN/GTALK (Depends on APK )
Office Software: WORD/EXCEL/PDF(Depends on APK install)
Operation Temperature: 0~60℃
Storage Temperature: -10~60℃
Humidity Environment: 5%-90%(No condensation)
Certificate: CE, FCC
Product weight: 300g
Product size (L x W x H): 13.00 x 12.00 x 2.00 cm / 5.12 x 4.72 x 0.79 inches
Color: Black
Firmware version: updated at first boot from version 0.0.7 to version 0.0.8
Build number: AM6-userdebug 9 PPR1.180610.011 20190717 release-keys
Source code version: 6478b23_clean
Kernel version: 4.9.113
Android Security patch level: August 5, 2018

Audio Out
Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing I2S audio interface supporting 2-channel input and 8-channel (7.1) output
Built-in serial digital audio SPDIF/IEC958 output and PCM input/output
Built-in stereo audio DAC,
Stereo digital microphone PDM input
Support concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM

Video CODEC
VP9 Profile-2 up to 4Kx2K@60fps H.265 HEVCMP-10@L5.1 up to 4K*2K@60fps
H.264 AVC HP@L5.1 up to4K*2K@60fps
H2.64 MVC up to1080P@60fps
MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)
WMV/VC-1 5P/MP/AP up to 1080P@60fps
AVS-P16(AVS+)/AVS-P2 jiZhun Profile up to 1080P@60fps
MPEG-2 MP/HL up to 1080P@60fps(ISO-13818)
MPEG-1 MP/HL up to 1080P@60fps(ISO-11172)
Realvideo 8/9/10 up to 1080P
WebM up to VGA
Multiple language and multiple format sub-title video support
MJPEG and JPEG unlimited pixe resolution decoding(ISO/IEC-10918)
Supports JPEG thumbnail, scaling, rotation and transition effects
Support *.mkv,*.wmv,*.mpg,*.mpeg,*.dat,*.avi,*.mov,*.iso,*.mp4,*.rm
and *.jpg file formats

UGOOS AM6 Smart TV Box Interface
1 x Full size USB 3.0
3 x Full size USB 2.0
1 x Charging DC 12V port
1 x micro SD / TF card slot
1 x HDMI 2.1 out
1 x AV jack output
1 x Aux-in
1 x Ethernet LAN RJ45 port
1 x Optical audio out
1 x Maskrom button
1 x Recovery button
1 x Power on / off button
2 x WiFi antenna
1 x Led Work Light

Package content
1 x UGOOS AM6 S922X Android 9.0 TV Box
2 x Dual-band Antenna
1 x HDMI Cable
1 x Power Adapter model R241-1202000E 12V 2A
1 x English User Manual
1 x IR Remote control

Photo gallery full album here. Official webpage here. More about Ugoos devices here.

UGOOS AM6 UGOOS AM6 UGOOS AM6 UGOOS AM6 UGOOS AM6 UGOOS AM6 UGOOS AM6 UGOOS AM6

About Ugoos Ugoos Industrial is a China Mainland based company with international developers team. Main directions are: ARM Hardware & Software Development, TV Boxes and Dongles, Digital Signage and Advertisement Solutions. Ugoos Industrial Co., Ltd. is the first on the market created Dual core and Quad core TV dongle. Our main directions are designing, R&D, manufacturing, and marketing on the Android HD Media Players market. In early 2011, Ugoos developed the first Dual core Android TV dongle in the world. As the leading company of Smart TV dongles and TV boxes in China, Ugoos has a European Development Team in China. Our team always insists on the principles of high quality products, quality service, and win-win relationships.
