Unboxing ACEMAGICIAN AD15 Intel I5-12450H 16GB DDR4 RAM 512GB Mini PC

Best Deal Alert! You can now buy ACEMAGICIAN AD15 Intel I5-12450H 16GB DDR4 RAM 512GB Mini PC from Amazon.com with 29% off if you’ll use our coupon code: AYNHKMGQ. Hurry up, limited time offer!


Meet ACEMAGICIAN AD15 Mini PC
The ACEMAGICIAN AD15 Mini PC is a compact desktop computer with support for up to triple displays, Ethernet port, Wi-Fi6 and Bluetooth 5.2. It’s not the most powerful mini PC on the market, but it’s fairly versatile system with a beautiful design and silent operation. And it’s not expensive at all.

The Intel Core i5-12450H is a high-end CPU based on the Alder Lake architecture. It was announced in early 2022 and offers 4 of the 6 performance cores (P-cores, Golden Cove architecture) and 4 of the 8 efficient cores (E-cores, Gracemont architecture) leading to 8 cores in total (octa core CPU). The base clock frequency of the CPU is 2000 MHz, but due to Turbo Boost technology, it can perform up to 4400 MHz. The size of the L3 cache is 12 MB. This chip has integrated graphics Intel UHD Graphics.Intel is building the Core i5-12450H on a 10 nm production process. With a TDP of 45 W, the Core i5-12450H consumes typical power levels for a modern PC. Intel’s processor supports DDR4 and DDR5 memory with a dual-channel interface. For communication with other components in the system, Core i5-12450H uses a PCI-Express Gen 4 connection. Hardware virtualization is available on the Core i5-12450H, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.

The 16GB DDR4 memory also helps the computer to run multiple applications simultaneously, as well as access frequently-used files and programs. Files can be stored locally on the 512GB NVME SSD, while the 5 USB ports provide connections for multiple peripherals and accessories. We have also triple video output with two HDMI 2.0 and USB Type-C outputs that allow us maximum video resolutions up to 4K@60Hz. Connect wireless peripherals with Bluetooth 5.2 and go online without any cables with Wi-Fi 6. A Gigabit LAN port is also present, supporting a very fast wired Ethernet connection. It runs on the 64-bit Windows 11 Pro operating system out of the box.

ACEMAGICIAN AD15 Mini PC can handle diverse applications easily, widely used in various occasions like daily work, online streaming, heavy gaming, design or home entertainment. It’s compact size makes you business trip easier and burdenless. It’s definitely a good conpanion for your work, study and daily life. This mini computer’s compact small size, durability, high reliability, universal performance and low power requirement help users getting much better computing experience. Netflix, HBOmax, Youtube 4K – everything works just fine, AD15 is giving you the ultimate experience in streaming performance. The smaller size expands the scope of application, and the design is still suitable for the office. Three monitors can be connected at the same time. The plastic shell is very durable, so that you can put it in a travel bag and take it with you on trips.

Using the appropriate tools, the Acemagic AD15 can be opened without any problems. Looking from the front, the right side is fastened with some screws at the bottom. After removing them, the side cover can simply be slid toward the bottom to remove it. But this doesn’t give you many options yet, and you have to open the device further if you want to access WLAN module or clean the fan. But even that won’t be much of a problem if you use some skill.

There’s a lot to like about the ACEMAGICIAN AD15 Mini PC. It’s conveniently-sized and could easily fit into even the most tightly-packed desktops. It’s also highly versatile, with a range of different ports, mounting options, and configurations available to suit almost every conceivable home or office. If you are looking for a small desktop PC that is more than capable for your everyday basics, yet still affordable enough as not to break your bank, the ACEMAGICIAN AD15 is too good of an option to be overlooked.

Advantages of using ACEMAGICIAN AD15 Mini PC
– Powerful Performance: The Intel Core i5-12450H processor provides strong performance for a mini PC. It can handle a wide range of tasks, including office work, web browsing, content creation, and even some gaming.
– Multitasking: With 16GB of DDR4 RAM, you can run multiple applications simultaneously without experiencing slowdowns. This is great for productivity and multitasking.
– Fast Storage: The 512GB storage capacity is typically provided by an SSD (Solid State Drive), which offers fast read and write speeds. This ensures quick boot times and responsive application performance.
– High-Resolution Display: The 4K support allows you to connect to and use 4K displays, providing stunning visuals and excellent clarity, which is particularly beneficial for media consumption, graphic design, and video editing.
– Wireless Connectivity: WiFi 6 (802.11ax) offers faster and more stable wireless internet connectivity, which is useful for streaming, online gaming, and downloading large files. Bluetooth 5.2 provides compatibility with a wide range of wireless peripherals.
– Triple-Screen Output: The ability to connect to three screens simultaneously is advantageous for professionals who require a multi-monitor setup for tasks like video editing, 3D modeling, and data analysis.
– Compact and Space-Saving: Mini PCs are small and compact, saving space on your desk or in your living room. They are ideal for those with limited space.
– Portability: Mini PCs are often lightweight and easy to transport, making them a convenient option for users who need computing power on the go or want to set up a flexible home entertainment system.
– Energy Efficiency: Mini PCs typically consume less power compared to full-sized desktop computers, which can lead to energy savings over time and a reduced environmental footprint.
– Quiet Operation: Mini PCs tend to have efficient cooling solutions and produce less noise compared to larger desktops, making them suitable for quiet work environments and home theater setups.
– Versatility: These mini PCs can serve various purposes, including as a home theater PC (HTPC), a small office computer, a media server, or a digital signage player, depending on your needs.
– Modern Aesthetics: Many mini PCs have sleek and modern designs that blend well with contemporary home or office setups.
– Customization: This mini PCs allows for component upgrades, such as RAM or storage, giving you the flexibility to tailor the system to your specific needs.
– Lower Maintenance: Mini PCs typically generate less heat and dust buildup due to their compact design, resulting in lower maintenance requirements.

ACEMAGICIAN AD15 Mini PC Features
– High performance intel processor. AD15 Mini PC Built-in Intel i5-12450H Processor(8Cores,12Theads)Up to 4.4GHz,Intel UHD Graphics (Graphics Frequency 1.2 GHz), widely used in light gaming,photo editing, etc, in-home and business It performs well in home and business work.
– 16GB DDR4 512GB SSD. Upgrade Friendly-This Mini Computer comes with DDR4 8GBx2 memory (Max up to 64GB) + M.2 2280 512TB PCIe 3.0 SSD storage (up to 2TB). It supports ultra-high speed PCIe 3.0 SSD, the read and write speed is about 4 times faster than SATA SSD, the operating system and games will run faster. It also equipped with one 2.5-inch SATA HDD (SATA 3.0 6.0Gb/s) slots.Large Storage makes you don’t worry about memory problems.
– 4K Screen display support. AD15 Mini PC comes with a 4K@60Hz ultra-high-definition graphics card (Intel UHD Graphics ) to support 4K@60Hz high-definition video playback and enjoy a high-quality visual experience. 2* HDMI ports and 1*TYPE-C support 4K triple-screen output, three-screen collaboration meets your needs and can double your work efficiency.
– WiFi 6 & Bluetooth 5.2. Wi-Fi 6 boasts speeds up to 3x faster than Wi-Fi 5, you can quickly browse websites, stream movies without buffering, and download files with ease. Bluetooth 5.2 allows quick connections to your wireless keyboard, mouse, speakers, and other devices, freeing you from the mess of wired desktops.
– Better Service. ACEMAGIC is committed to providing high-quality service to every customer and offers a 12-month warranty for each product. If there are any problems with the product during this period, the buyer can immediately replace it with a new machine. Customer satisfaction is always ACEMAGIC’s sole pursuit.

ACEMAGICIAN AD15 Mini PC Highlights
– Compact & Ultra High-efficiency Mini PC
– Powerful processing
– Lightning-fast memory and high-speed storage
– Low energy consumption
– Advanced hardware & software security features
– High-Speed Network
– Triple Display outputs
– Very easy to make memory upgrades.

ACEMAGICIAN AD15 Mini PC BIOS
The Ami BIOS of ACEMAGICIAN AD15 Mini PC is pretty rich in features and options. There are 5 tabs in settings, with a few options each: Main, Advanced, Security, Boot, Save & Exit. I have made a BIOS back-up, you can download it from here. I advise everyone to make a copy of a working BIOS, if possible, before doing BIOS experiments. To do that you can simple use the provided Aptio AfuWin64 software. If you disabled USB in the BIOS, or if you did another mess in device BIOS, only overwriting NVRAM can reset BIOS settings. In this way, there is no need to open the case, to teardown the device to be able to reset the CMOS. All the actions are made from Windows environment, so your Mini PC has to be able to boot into Windows. All the following actions that are you will do next are entirely at your own risk.

BIOS details
BIOS Vendor: American Megatrends Aptio – AMI
BIOS version: 2.22.1284
Core version: 5.25
Project Version: NP15004 / 00.39
Firmware ID: 1AXFE039
BIOS Chip Name: Wnbond 25X/Q Series
Compliancy: UEFI 2.7; PI 1.6
Build date: 03/18/2023 11:09:46
Processor name: AlderLake ULT
Processor Type: 12th Gen Intel(R) Core (TM) i5-12450H
Features: Wake On LAN, UEFI, PXE Auto power on when power failure

ACEMAGICIAN AD15 Mini PC Windows 11 Drivers
ACEMAGICIAN AD15 Mini PC came with Windows 11 Pro 64-bit edition version. This version was activated and everything was just ok. All the drivers were correctly installed and untill now everything runs just great. The Windows version was 22H2 Build 22621.2283.

Installed drivers for: Audio inputs and outputs, Bluetooth, Computer, Disk drives, Display adapters, Firmware, Human Interface Devices, IDE ATA/ATAPI controllers, Keyboards, Mice and other pointing devices, Monitors, Network adapters, Portable Devices, Ports (COM & LPT), Print queues, Processors, Security devices, Software components, Software devices, Sound, video and game controllers, Storage controllers, System devices and Universal Serial Bus controllers.

I extracted with DoubleDriver the drivers for Windows 11 Pro version 22H2, you can download the archive from here. Use the provided Double Driver application (as Admin) to simply restore the missing drivers from your collection, just locate the extracted folder.

About System
Processor: 12th Gen Intel(R) Core(TM) i5-12450H 1.10 GHz
Installed RAM: 16.0 GB (15.7 GB usable)
Storage: 512GB SSD
System type: 64-bit operating system, x64-based processor
Pen and touch: No pen or touch input is available for this display
Edition: Windows 11 Pro
Version: 22H2
Installed on: ‎9/‎18/‎2023
OS build: 22621.2283
Experience: Windows Feature Experience Pack 1000.22662.1000.0

ACEMAGICIAN AD15 Ports
1 x Power On / Off button
1 x DC in port
4 x USB 3.0 port
1 x USB Type-C port
1 x Audio Line out Jack / Mic TRRS
2 x HDMI 2.0 port
1 x RJ45 Gigabit LAN port
1 x Power LED light
1 x Kensington Lock Security Slot

ACEMAGICIAN AD15 Mini PC Specs
Brand: ACEMAGIC
Model: AD15
Model number: CMNAD150BEU1650
CPU: 12th Gen Intel® Core™ i5-12450H, 12M Cache, up to 4.40 GHz
GPU: Intel® UHD Graphics
Memory: 16GB DDR4 RAM SODIMM 3200MHz, expand up to 64GB
Storage: Installed 512GB M.2 2280 NVMe SSD, expand up to 2TB
Video output: HDMI 2.0 + USB Type-C ports
WiFi: WiFi 6 802.11ax, m.2 PCle port
Bluetooth: v5.2
LAN: RJ45 LAN, 1000Mbs Gigabit Ethernet
Power Input: Input: 100-240V AC, 50/60Hz
Power Output: 19V 6.3A DC 119.7W
Work/Storage Environment: -10°C–45°C,30%–85% Humidity/-20°C–60°C,10%–90% Humidity
Color: Black / Silver / Gray
VESA Support: 70×70 mm / 100×100 mm
OS version: Windows 11 Pro version 22H2 Build 22621.2283
Plug: EU / US / UK / JP

Package Content
1 x ACEMAGICIAN AD15 Mini PC
1 x Power Adapter model CGSW120-190-06300I 19V 6.3A DC 119.7W
1 x HDMI cable (80 cm)
1 x Multi-language User Manual (EN / ND / FR / DE / IT / CN / PL / ES / SE)



Unboxing Photo Album with Hi-Rez images here. Official webpage here. More about AceMagic devices here.

About AceMagic. We are passionate about empowering individuals and businesses with cutting-edge technology that helps them achieve more and reach their full potential with our personal consumer microelectronics. In 2013, a group of tech enthusiasts were inspired by the “Magician Impossible” series. They set out to create a brand that would deliver computing solutions that were not only powerful but also fun and accessible. Today, Acemagician is leading the way in miniaturizing personal electronic devices, making technology more convenient, portable, and accessible. Our brand slogan, “Mini Space, Big World,” reflects our mission to bring the magic of technology to the world of personal consumer microelectronics. To provide powerful mini PCs that empower individuals and businesses to unleash maximum computing power in a compact form factor, enabling them to work and create from anywhere. We are committed to sustainability and strive to offer portable computing solutions that reduce environmental impact while providing cutting-edge technology. Through our innovation and dedication to efficient computing, we aim to enable people to achieve more with limited space and resources.

Did this article help you? If so, please tell me in a comment what do you think about it.

Don’t miss any of our future video tutorials, follow us on Youtube. Like us on Facebook. Join our Best Deals Telegram Channel. Join our Android TV Box Firmware Updates Telegram Channel. Subscribe now to our newsletter. If you need Tech Reviewer or Youtube Influencer read this. Donate now here to support CGR Team!
