Unboxing Beelink Kaby G7, Probably the Best Mini Gaming PC

Posted in Jan 13, 2020 in Unboxing, no comment

Best Deal Alert! You can now buy Beelink Kaby G7 Turbo Gaming Mini PC from Amazon.com, Banggood.com or Geekbuying.com.

Meet Beelink Kaby G7, Probably the Best Mini Gaming PC
Beelink has made another big move forward and now it is designing the top-notch mini PCs that are ready to beat any top brand out there.

The Beelink Kaby G7 is a real beast. It is impressing with the scary graphics on the top. In front, we see the power key in red as well as a headphone jack. Interestingly, the rest of the interfaces are placed on one rear side. They include five USB 3.0 ports, two HDMI ports, two DP ports, a microphone port, an SPK port, a Gigabit LAN port, a security keyhole, and a DC port. The same side also carries a ventilation grill. Generally, it has a cube form and the materials it uses is high-quality metal.

The Beelink Kaby G7 is packed with the latest 8th-gen Intel Kaby Lake i7-8709G chip. In its turn, this SoC comes with an Intel HD Graphics 630 / Radeon RX Vega M GH Graphics (with an independent 4GB HBM2 graphics video memory), 16GB of DDR4 RAM, 256GB SSD drive, and 1TB HDD. The lower variant is packed with the i5 version uses four cores and 8 thread clocked at 3.8GHz. Due to the powerful hardware, it doesn’t face any problem when handling any kind of task or playing a 4K video at H.265 decoding. Apart from the number of interfaces, the Beelink Kaby G7 supports dual-band WiFi 2.4GHz + 5.8GHz and Bluetooth v4.0.

Beelink Kaby G7 Features
– Intel Kaby Lake i7-8709G quad-core 8 thread 3.8GHz CPU ,Intel HD Graphics 630 RadeonTM RX Vega M GL GPU
– Use RAM DDR4 16GB ROM 256GB M.2 2242 SSD,Support 4TB 2.5 inch HDD
– Dual HDMI interface + DisplayPort1.4 + DisplayPort1.2, multiple monitor outputs. H.265 decoding and 4K video display
– High performance CPU and high quality heat dissipation, Support 3D rendering software and Large online game
Beelink Kaby G7 Highlights
● Intel Kaby Lake i7 – 8709G CPU, quad-core, 8 thread
● Intel HD Graphics 630 + Radeon RX Vega M GH GPU
● Support 4TB or 2.5 inch HDD
● Support H.265 decoding, saving bandwidth
● Support 4K video display
● 1000Mbps Ethernet, fast network access
● 2.4GHz + 5.8GHz dual-band WiFi
● Bluetooth v4.2

Beelink Kaby G7 Mini PC Ports
5 x Standard USB 3.0 Port
2 x HDMI 2.0 4K 60Hz Port
2 x DP 1.3 4K Port
1 x Ethernet RJ45 Gigabit 1000Mbps LAN Port (Intel i219V)
1 x Headphone microphone jack
1 x Mic jack
1 x Speaker jack
1 x 19V DC in Port
1 x Power Button
1 x Kensington Lock
1 x RGB LED on top
1 x Front LED
1 x NVMe 2280 PCIe 4x (internal)
2 x 2.5″ SATA (internal)
1 x free SODIMM slot (internal)
1 x Power On/off button

Beelink Kaby G7 Mini PC Specs

Brand: Beelink / AZW
Model: Kaby G7 / KB-G Mini PC
Type: Gaming Mini PC
OS: Windows 10 Home 64bit v1903
CPU: Intel Core i7-8709G Quad Core
GPU: Radeon RX Vega M GH 1,2GHz 4GB VRAM HBM2 24 CU / Intel HD Graphics 630 350MHz 1,10GHz
RAM: 16GB DDR4 2677MHz SODIMM (free 1x SODIMM)
Storage: 256 SSD NVMe 2280 PCIe 4x + 1TB 2.5″ HDD
WIFI: 802.11 a/b/g/n/ac, Dual-band WiFi 2.4GHz/5GHz
Bluetooth: v4.2 (Intel 3165)
LAN: Ethernet Gigabit
RJ45 Port Speed: 1000Mbps
Power Supply: Charge Adapter
Power Consumption: 180 W
Power Type: External Power Adapter Mode
Power Input Vol: 19V / 9.47A
Power Adapter Input: 100-240V / 50-60Hz
Battery Type: CR2032 Button Battery
Battery Capacity: 210mAh
Product weight: 1.3620 kg
Product size (L x W x H): 17.30 x 15.30 x 6.50 cm / 6.81 x 6.02 x 2.56 inches
Materials: Plastic and metal
Color: Black & Red
BIOS Version: AZW-BI-MINIPC-H3VR220-102-A

Package Content
1 x Beelink Kaby G7 Mini PC
1 x Power Adapter DC 19V 9.47A model HKA18019095-7A
1 x HDMI cable
1 x DP cable
1 x Multi-language User Manual (EN / DE / ES / IT / FR / RU / CN)
1 x Intel Mini PC User Help card
1 x Hard Disk Cable
1 x AC Cable
